Sony MVS-7000X User Manual

257
Applying Special Effects (Effects on the Overall Video Signal)
Chapter 11 DME Operations
a) Specify minus values to stretch the image in the vertical direction,
and plus values to stretch the image in the horizontal direction.
16:9 mode
a) Specify minus values to stretch the image in the vertical direction,
and plus values to stretch the image in the horizontal direction.
Sepia Settings
Applying the Sepia effect
1 In the DME menu, select VF2 ‘Video Modify’ and
HF3 ‘Color Modify.’
The Color Modify menu appears.
2 Press [Sepia], turning it on.
3 Set the following parameters.
4 To set the color of the sepia image, press [Sepia
Color], turning it on, and adjust the parameters.
Masking the Sepia effect with a selected
pattern
Press [Mask] to display the Mask menu, and set the pattern
type and modifiers (see page 261).
Mono Settings
Applying the Mono effect
1 In the DME menu, select VF2 ‘Video Modify’ and
HF3 ‘Color Modify.’
The Color Modify menu appears.
2 Press [Mono], turning it on.
Masking the Mono effect with a selected
pattern
Press [Mask] to display the Mask menu, and set the pattern
type and modifiers (see page 261).
Posterization and Solarization
Settings
You can specify the degree of luminance coarsening.
You can specify the degree of chroma coarsening.
Applying the Posterization or Solarization
effect
1 In the DME menu, select VF2 ‘Video Modify’ and
HF3 ‘Color Modify.’
The Color Modify menu appears.
2 Press [Poster/Solar], turning it on.
3 Set the parameters.
4 Aspect Aspect ratio
of shrunken
images
–100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 Center X x-value of
shrinking
center point
–4.00 to +4.00 (SD)
–16.00 to +16.00
(HD)
2 Center Y y-value of
shrinking
center point
–2.25 to +2.25(SD)
–9.00 to +9.00 (HD)
3 Size Shrinking
ratio
0.00 to 100.00
4 Aspect Aspect ratio
of shrunken
images
–100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 Mix Y Y signal mix
amount
0.00 to 100.00
2 Mix C Chroma
signal mix
amount
0.00 to 100.00
3 Mix All Y signal and
chroma
signal mix
amount
Mix Y value shown
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Hue 359.99 to 0.00
Knob Parameter Adjustment Setting values
Knob Parameter Adjustment Setting values
1 Poster Coarseness
of luminance
gradations
(Posterization
parameter)
0.00 to 100.00
2 Solar Coarseness
of chroma
gradations
(Solarization
parameter)
0.00 to 100.00
