Sony PlayStation 5 User Manual

EN
9
Install an M.2 SSD
2
Remove the screw from the expansion slot cover and then remove the
cover.
3
Remove the screw and spacer, and then adjust the spacer to the size of
the M.2 SSD.
Expansion slot cover
Screw
Spacer
4
Holding the edge of the M.2 SSD, align it with the notch on the
expansion connector. Tilt the M.2 SSD diagonally upward, and firmly
insert it all the way into the expansion connector.
The following shows an M�2 SSD with a heat sink and heat transfer sheet attached�
5
Tilt the M.2 SSD down and fasten it with the screw.
6
Attach the expansion slot cover and fasten the screw.
7
Attach the cover (page 7).
8
Attach the feet, connect the AC power cord and cables, and then turn
on the power.
When your PS5 console turns on, the formatting guide appears� Follow the on-
screen instructions and format the M�2 SSD�

Sony PlayStation 5 Specifications

General

Product color	Black, White
Internal memory	16000 MB
Processor cores	8
Processor model	AMD Ryzen Zen 2
Graphics processor	AMD Radeon
Processor frequency	3.5 GHz
Internal memory type	GDDR6
Processor manufacturer	AMD
Graphics processor frequency	2230 MHz
Graphics processor performance	10.3 TFLOPS
Number of controllers supported (max)	2
Power supply	350 W
Package depth	174 mm
Package width	469 mm
Package height	426 mm
Recommended gender	Boy/Girl
Storage media	SSD
Built-in optical drive	Yes
Card reader integrated	No
Internal storage capacity	825 GB
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.1
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Cables included	HDMI, USB
Game controllers included	Gamepad
Number of gamepads included	1
USB 2.0 ports quantity	0
HD type	8K Ultra HD

Weight and Dimensions

Depth	260 mm
Width	390 mm
Height	104 mm
Weight	4500 g
