MPEG-2 Video Patent Portfolio License / Specifications
130
Appendixes
ANY USE OF THIS PRODUCT OTHER THAN
CONSUMER PERSONAL USE IN ANY
MANNER THAT COMPLIES WITH THE
MPEG-2 STANDARD FOR ENCODING
VIDEO INFORMATION FOR PACKAGED
MEDIA IS EXPRESSLY PROHIBITED
WITHOUT A LICENSE UNDER
APPLICABLE PATENTS IN THE MPEG-2
PATENT PORTFOLIO, WHICH LICENSE IS
AVAILABLE FROM MPEG LA, L.L.C., 250
STEELE STREET, SUITE 300, DENVER,
COLORADO 80206.
“PACKAGED MEDIA” means any storage
media storing MPEG-2 video information such as
DVD movie which are sold/distributed to general
consumers. Disc replicators or sellers of the
PACKAGED MEDIA need to obtain licenses for
their own business from MPEG LA. Please
contact MPEG LA for any further information.
MPEG LA. L.L.C., 250 STEELE STREET,
SUITE 300, DENVER, COLORADO 80206
http://www.mpegla.com
Power requirements
DC 12 V
Power consumption
Approx. 12 W (Typical) (Recording,
EVF On, LCD monitor Off)
Peak inrush current
(1) Power ON, current probe method:
15 A (240V)
(2) Hot switching inrush current,
measured in accordance with
European standard EN55103-1:
62 A (230V)
Operating temperature
0ºC to +40ºC (32ºF to 104ºF)
Storage temperature
–20ºC to +60ºC (–4ºF to 140ºF)
Recording/playback formats
Video
HQ mode: MPEG-2 MP@HL,
35 Mbps / VBR
1920 × 1080/59.94i, 50i, 29.97P, 25P,
23.98P
1280 × 720/59.94P, 50P, 29.97P, 25P,
23.98P
SP mode: MPEG-2 MP@H-14,
25 Mbps /CBR
1440 × 1080 /59.94i, 50i
(23.98P is converted to 59.94i in 2-3
pull-down processing.)
Audio
LPCM (16 bits, 48 kHz, 2 channels)
Recording/playback time
With one SBP-8
SP mode: Approx. 35 min.
HQ mode: Approx. 25 min.
With one SBP-16
SP mode: Approx. 70 min.
MPEG-2 Video Patent
Portfolio License
Specifications
General
