10
Rating label
This label shows the name
of the camera and
its electric rating.
Important
The product name and electric rating are
located at the bottom of the camera.
Infrared Remote Commander
(supplied)
MENU button
Press the button to display or not to display
the
OSD menu.
Notes
• The OSD menu is not displayed on the SDI
output image when the [Menu Overlay
(SDI)] check box on the Web App menu is
not selected.
• The OSD menu is not displayed on the
HD
MI output image when the [Menu
Overlay (HDMI)] check box on the Web App
menu is not selected.
OSD m
enu operation button
Operates the camera OSD menu.
Press the SET button when selecting.
CA
NC./BACK button
Press this to cancel the setting in the camera
O
SD menu, or return to the previous screen.
PA
N-TILT button
Press the arrow buttons to pan or tilt the
c
amera. Press the HOME button to have the
camera return the position facing forward.
To Next Page
