7
ST-S3
3-5. TUNER PACK (FM/AM)
3-4. PANEL BOARD, SIRCS BOARD
6
SIRCS board
2
two screws
(BVTP2.6
×
8)
2
four screws
(BVTP2.6
×
8)
2
screw
(BVTP2.6
×
8)
4
PANEL board
1
wire (flat type) (19 core
)
(CN602)
3
two claws
5
two claws
3
tuner pack (FM/AM)
2
two screws
(BVTP3
×
8)
1
wire (flat type) (15 core)
(CN506)
