545
Example of File Contents
XptRowAssign MEBank? ME1 to ME5, PP Target control block
Row? 1st to 4th Target button row
BusFunction? A, B, Key1 to Key8,
Utility1, Utility2,
DMEExternalVideo,
DMEUtility1, DMEUtility2,
EditPreview,
Aux1 to Aux48,
FrameMemory1,
FrameMemory2,
DME1Video to DME4Video,
DME1Key to DME4Key,
UtilShotbox1 to UtilShotbox10
Target bus/function
GPITestFire Box? DCU Target GPI
The target to set is “DCU” only, and cannot be
changed.
Port? 1 to 50 Target GPI output port
NetworkMessaging Device? 1 to 12 Target device
Command? Command Command (up to 23 characters)
XptTableForRow MEBank? ME1 to ME5, PP Target control block
Row? 1st to 4th, 3rd&4th, All Target button row
Table? Main, Table1 to Table14,
BankTable (a)
Cross-point assign table
(a): Table configured on a switcher bank
MacroTake Register? All (a) Target macro register
(a): All paused macros
MacroCancel Register? All (a) Target macro register
(a): All simultaneously executing macros
PrevKF Region? Current (a) Target region
(a): Currently selected region
NextKF Region? Current (a) Target region
(a): Currently selected region
TransitonRate ME? ME1 to ME5, PP Target control block
Transition? Background, Key1 to Key8 Target transition
Time? 0 to 999 Transition rate (number of frames)
Line Content Description
1 PNL 0001PNL_0000.PMRMACROREG File header
2 #,Sample, Comment
3 Event?,Snapshot,Region?,ME1,Register?,1,Attribute?,Off,Time?,
Current
Simultaneously recall snapshots from register
number 1 in the M/E-1 and DME1 regions.
4 Continue?,Snapshot,Region?,DME1,Register?,1,Attribute?,Off,
Time?,Current
5 Event?,MEXpt,ME?,ME2,MEBus?,A,Xpt?,121,VideoKey?,Video Select button number 121 on the M/E-2 A bus.
Symbol Parameter name Arguments Description
