407
For output connectors not assigned, select [Inhibit].
4
Press [Set].
Adjusting Video Clips
1
In the Engineering Setup >Switcher >Output menu
(7333), press [Video Clip].
The Video Clip menu (7333.2) appears.
2
Select the target output to set.
3
Set the following parameters.
To return the parameters to their default settings
Press [Default].
Setting the Vertical Blanking Interval
and Through Mode
1
In the Engineering Setup >Switcher >Output menu
(7333), press [V Blank/Through].
The V Blank/Through menu (7333.3) appears.
2
Select the target output to set.
3
Press [V Blank Mask], and set the following
parameter.
a) The adjustment range varies as follows, depending on the signal
format.
3840×2160P (including outputs with active area of 4096×2160), 1080P:
15 to 41
1080PsF, 1080i: 7 to 20
720P: 7 to 25
To return the parameters to their default settings
Press [Default].
4
To enable through mode, press [Through Mode],
turning it on.
Through mode can be enabled for the following
outputs.
• AUX1 to 48 and edit preview outputs
• Program outputs of each M/E and PGM/PST bank
• Clean outputs of each M/E and PGM/PST bank
Setting the Safe Title Area
Safe titles cannot be used on outputs where the active area
is set to [4096×2160].
1
In the Engineering Setup >Switcher >Output menu
(7333), press [Safe Title].
The Safe Title menu (7333.4) appears.
2
Select the target output to set.
3
Press [Safe Title], turning it on, to enable the safe title
setting in the Misc >Safe Title menu (3221).
4
Perform the following operations.
To display a box: Press [Box1] or [Box2], turning it
on.
To display a cross: Press [Cross], turning it on.
To display a grid: Press [Grid], turning it on.
5
Perform the following operations, according to the
selection in step 4.
When [Box1] or [Box2] is selected: Set the following
parameters.
a) Adjustable for [Box2].
When [Grid] is selected: In the <Grid Size> group,
set the grid size relative to the picture frame
(80.00%, 85.00%, 90.00%, 100.00%).
6
Perform the following operations, according to the
selection in step 4.
When [Box1] or [Box2] is selected: In the <Box1
Adjust> or <Box2 Adjust> group, select the screen
aspect ratio (16:9, 14:9, 4:3).
When [Grid] is selected: In the <Grid Adjust> group,
select the screen aspect ratio (16:9, 4:3).
No. Parameter Adjustment
2 White Clip Luminance signal white clip value
3 Dark Clip Luminance signal dark clip value
4 Chroma
Clip
Chrominance signal clip value
No. Parameter Adjustment
2 Mask End Final value for vertical blanking
interval
a)
Note
No. Parameter Adjustment
2 Box Size Box size
3 Luminance Display color brightness
a)
To Next Page
