Edition Manual Chapter Page
2014-03-31 Workshop Manual, GGP Park 3 Steering 1
3 Steering
Contents in this chapter
General
The articulation steered machines are equipped with either a common mechanical system
or a hydraulic assisted steering system. Both systems work with wires or chains,
depending on the model. The hydraulic assisted system gets its power from the variable
hydraulic transmission at the rear shaft.
This chapter contains a brief description of the function and describes repair, replacements
and adjustments of stressed parts of the steering system.
3.3 Bearings, steering shaft ......... 7
3.3.1 Replacement of sliding
bearings and ball bearings ... 7
3.3.2 Replacement of upper
ball bearing
(with steering booster)............ 8
3.3.3 Trouble shooting.................... 9
3.1 Description ..............................2
3.1.1 Mechanical system ................2
3.1.2 Hydraulic assisted system .....2
3.2 Steering wires ..........................4
3.2.1 Assembly ...............................4
3.2.2 Adjustment ............................5
3.2.3 Steering chains ......................5
