FCB-KM
English
18
Definitions
1 Cutting Blade
Metal cutting blade for cutting
weeds and soft green plants.
2 Deflector
Designed to reduce the risk of injury
from foreign objects flung
backwards toward the operator by
the cutting attachment and from
contact with the cutting attachment.
3 Drive Tube
Encloses and protects the drive
shaft between the coupling sleeve
and gearbox.
4 Depth Wheel
Deflector-mounted depth wheel
rolls on ground and keeps edger
cutting blade at preset height for
required depth of cut.
5 Wingnut
Must be loosened to shift the wheel
to adjust the depth of cut.
6Skirt
Designed to reduce the risk of injury
from foreign objects flung
backwards toward the operator by
the cutting blade.
7 Wear Guard
Protects the gearbox from wear.
8 Gearbox
Reduces engine speed to speed
required to drive the edger blade.
Weight
Users of this unit should carry out only
the maintenance operations described
in this manual. STIHL recommends that
other repair work be performed only by
authorized STIHL servicing dealers.
Warranty claims following repairs can be
accepted only if the repair has been
performed by an authorized STIHL
servicing dealer using genuine STIHL
replacement parts.
Genuine STIHL parts can be identified
by the STIHL part number, the
{ logo and, in some cases, by
the STIHL parts symbol K. The
symbol may appear alone on small
parts.
Specifications
with deflector and
blade: 4.4 lbs. (2.0 kg)
Maintenance and Repairs
