Stihl FS 120 User Manual

38
English / USA
FS 120, FS 120 R, FS 200, FS 200 R, FS 250, FS 250 R
: Remove the filter element and
inspect it – replace if dirty or
damaged – do not clean.
: Install filter element in the cover.
: Refit the filter cover.
Exhaust emissions are controlled by the
design of the fundamental engine
parameters and components (e.g.
carburation, ignition, timing and valve or
port timing) without the addition of any
major hardware.
General Information
The carburetor comes from the factory
with a standard setting.
This setting is designed to provide an
optimum fuel-air mixture under most
operating conditions.
With this carburetor it is only possible to
adjust the engine idle speed within fine
limits.
Motor Management Adjusting the Carburetor
LA
H
L
1
250BA039 KN

Stihl FS 120 Specifications

General

Power source	Gasoline
Type	Brush cutter
Cordless	Yes
Head type	Nylon line
Handle type	U-type handle
Engine power	1.8 hp
Product color	Black, Metallic, Orange
Uncertainty K	2 m/s²
Sound power level	110 dB
Fuel tank capacity	0.64 L
Vibration emission	4.9 m/s²
Engine displacement	30.8 cm³
Sound pressure level	98 dB
Cutting diameter (max)	- mm

Weight and Dimensions

Length	1760 mm
Weight	6300 g
