Stihl MS 280 C User Manual

61MS 280 C
English / USA
1= Carburetor box cover twist lock
2= Carburetor adjusting screws
3= Spark plug boot
4= Decompression valve*
(automatically resetting)
5= Chain sprocket cover
6= Chain sprocket
7= Chain brake
8= Adjusting wheel of quick
tensioner*
9= Side chain tensioner
10= Chain catcher
11= Bumper spike
12= Guide bar
13= Oilomatic saw chain
# Machine number
14= Oil filler cap
15= Muffler
16= Front hand guard
17= Front handle (handlebar)
18= Starter grip
19= Fuel filler cap
20= Master Control lever
21= Throttle trigger
22= Coasting brake activating lever
(Throttle trigger interlock)
23= Rear handle
24= Rear hand guard
* see "Guide to Using this Manual"
Main Parts of the Saw
#
3
9
150BA002 KN
1
2
5
6
78
10
11
12
13
4
24
19
18
23
14
150BA003 KN
15
16
17
20
21
22
