Sungrow SG125CX-P2 User Manual

7 iSolarCloud App User Manual
AFCI Parameters
The AFCI function may not be applicable in some areas. Please consult SUNGROW
for details.
Tap Settings > Operation Parameters > AFCI Parameters to enter the corresponding screen,
on which you can set AFCI Parameters.
figure 7-15 AFCI Setting
NS Protection (Passive Valid)
Tap Settings > Operation Parameters > Regular Parameters to enter the corresponding
screen, on which you can set the NS Protection(Passive Valid).
figure 7-16 NS Protection(Passive Valid)
7.8.3 Power Regulation Parameters
Active Power Regulation
Tap Settings > Power Regulation Parameters > Active Power Regulation to enter the
screen, as shown in the following figure.
98

Sungrow SG125CX-P2 Specifications

General

Max. DC Voltage	1100 V
Rated AC Power	125 kW
Max. DC Power	150 kW
Start-up Voltage	200 V
MPPT Voltage Range	200 V - 1000 V
Max. Short-circuit Current per MPPT	40 A
Max. AC Power	137.5 kW
Max. AC Current	198 A
Rated AC Voltage	400 V
Rated Grid Frequency	50/60 Hz
Total Harmonic Distortion	<3%
Power Factor Adjustment Range	0.8 leading to 0.8 lagging
DC Connection Type	MC4
Protection Class	IP66
Maximum DC Input Power	150 kW
DC Inputs per MPPT	2
Cooling Method	Smart forced air cooling
Operating Temperature Range	-25°C to +60°C
Humidity Range	0 - 100%
Communication	RS485, Ethernet
