9-14
INSPECTION AND MAINTENANCE
54G27-03E
83E010
Gear Oil
Specified Gear Oil
Manual transaxle/Transfer oil of auto-
matic transaxle model (AWD)
(API GL-4)
54G095
Rear differential oil (AWD)
(API GL-5 Hypoid)
54G096
When replacing gear oil, use the appropri-
ate viscosity and grade as shown in the
charts above.
We highly recommend you use:
API GL-4 SAE 75W-90 for manual tran-
saxle gear oil and transfer oil of automatic
transaxle model (AWD)
API GL-5 hypoid gear oil SAE 80W-90 for
rear differential oil (AWD)
CAUTION
Oil leaks from around the oil filter or
drain plug indicate incorrect installa-
tion or gasket damage. If you find any
leaks or are not sure that the filter
has been properly tightened, have
the vehicle inspected by your
SUZUKI dealer.
EXAMPLE
API GRADE
Manual transaxle/
Transfer oil (AWD A/T)
GL-4
Rear differential oil
(AWD)
GL-5 (Hypoid
gear oil)
Engine Coolant: 1, 2
To Next Page
