Suzuki CIAZ User Manual

7-35
INSPECTION AND MAINTENANCE
79MH0-74E
For windshield wipers:
79MM07033
1) Hold the wiper arm away from the win-
dow.
NOTE:
When raising both of the front wiper arms,
pull the driver’s side wiper arm up first.
When returning the wiper arms, lower the
passenger’s side wiper arm first.
Otherwise, the wiper arms may interfere
with each other.
54G130
2) Squeeze lock (1) towards wiper arm (2)
and remove the wiper frame from the
arm as shown.
3) Unlock the lock end of the wiper blade
and slide the blade out as shown.
Removal
79MM07034
Installation
79MM07035
(3) Locked end
EXAMPLE
(2)
(2)
(1)
(1)
EXAMPLE
EXAMPLE
(3)
(3)
EXAMPLE
