52
Engine overheats:
• Cooling water intake(s) are blocked.
• Engine is overloaded.
• Propeller is not properly matched to loads.
FUSE
1. Turn the ignition key to the “off” position.
2. Remove the motor cover.
3. Remove the fuse box cover and pull off the
fuse.
NOTE:
Use the fuse puller at the back of fuse box
cover, when the fuse is pulled off and installed.
4. Remove the Sub battery cable fuse.
5. Inspect the fuse and replace with new fuse if
needed.
Sub battery
cable fuse case
Normal fuse
Main fuse (60A)/
Isolator fuse (30A)
Blown fuse
Normal fuse
Blade type fuse
Blown fuse
