SERVICING INFORMATION 8-43
TIGHTENING TORQUE - REVISED 5/1999
ENGINE
ITEM N
.
m kgf
.
m lb-ft
Exhaust pipe bolt 23 2.3 16.5
Muffler mounting nut 23 2.3 16.5
Muffler joint nut 25 2.5 18.0
Speed sensor rotor bolt 18 1.8 13.0
Engine sprocket nut 145 12.5 105.0
Engine mounting bolt and nut (M:12) 75 7.5 54.0
(M:10) 55 5.5 40.0
Engine mounting thrust adjuster 10 1.0 7.0
Engine mounting thrust adjuster lock nut 45 4.5 32.5
Engine mounting pinch bolt 35 3.5 25.5
Cylinder head cover bolt 14 1.4 10.0
Spark plug 11 1.1 8.0
Cam chain guide bolt 10 1.0 7.0
Camshaft journal holder bolt 10 1.0 7.0
Cam chain tension adjuster bolt 8 0.8 6.0
Cam chain tension adjuster mounting bolt 10 1.0 7.0
Cylinder head side bolt 14 1.4 10.0
Cam chain tensioner bolt 10 1.0 7.0
Cylinder head bolt (M:10) 52 5.2 37.5
(M:6) 10 1.0 7.0
Cylinder nut 10 1.0 7.0
PAIR pipe nut 10 1.0 7.0
Water bypass union 14 1.4 10.0
Water inlet connector bolt 10 1.0 7.0
Oil hose union bolt 20 2.0 14.5
Clutch cover bolt 10 1.0 7.0
Clutch sleeve hub nut 95 9.5 68.5
Clutch spring set bolt 10 1.0 7.0
Clutch spring support bolt 23 2.3 16.5
Starter clutch cover bolt 10 1.0 7.0
Starter idle gear cover bolt 10 1.0 7.0
Starter clutch cover plug 11 1.1 8.0
Valve timing inspection plug 23 2.3 16.5
Starter clutch bolt 55 5.5 40.0
Generator cover bolt 10 1.0 7.0
Generator roter bolt 120 12.0 87.0
Generator stator set bolt 10 1.0 7.0
Crankshaft position sensor set bolt 5.5 0.55 4.0
Gearshift cover bolt 10 1.0 7.0
Gerarshift cam stopper bolt 10 1.0 7.0
Gearshift cam stopper plate bolt 10 1.0 7.0
Gearshift arm stopper bolt 19 1.9 13.5
Oil pressure switch 14 1.4 10.0
Crankcase bolt [M:6] 11 1.1 8.0
[M:8] 26 2.6 19.0
[M:9] 32 3.2 23.0
[M:10] 50 5.0 36.0
Oil gallery plug [M:6][M:8] 18 1.8 13.0
[M:10] 16 1.6 11.5
[M:16] 35 3.5 26.5
Oil drain plug 23 2.3 16.5
