7-31
INSPECTION AND MAINTENANCE
73SB7-01E
(For K12D engine model)
73SB010
1) Unclamp the side clamps (1), then pull
the air cleaner case toward you.
Remove the element from the air
cleaner case. If it appears to be dirty,
replace it with a new one.
2) Reinstall the air cleaner case securely.
(For K12M engine model)
75RM064
1) Unclamp the side clamps and remove
the element from the air cleaner case. If
it appears to be dirty, replace it with a
new one.
2) Clamp the side clamps securely.
Spark plugs
Spark plug replacement and inspec-
tion
(For K12C engine model)
81PN235
To access the spark plug:
1) Open the engine hood.
2) If necessary, disconnect the coupler (1)
while pushing the release lever.
3) Remove the bolts.
4) Pull out the ignition coils straight.
NOTE:
During installation, check that the wires,
couplers, sealing rubber of air cleaner
chassis and washers, are correctly
returned in place.
(1)
To Next Page
