1. Rear turn indicators
2. License plate light
3. Passenger footrests
4. Exhaust pipe
5. Rear/parking brake caliper
6. Rear brake disk
7. Oil filler cap/dipstick
8. Oil Filter screen
9. Main stand
10. Front fork
11. Tool kit
12. Luggage box
13. Fuse box
14. Battery
15. Diagnostic tool connector
16. Seat
17. Passenger handlebar
1
2
3
4
7
8
9
10
13
16
5
6
12 11
14
15
17
