<Set-up»
-ArWhen programming settings, disconnect motor
cable's.
Neutral
/
Maximum acceleration
/
Maximum reversing (Full
braking)
(J) Securely connect wiring according
to illustration
on
page
1
(except
motor).
Turn
on
transmitter first,
position throttle trim
to
neutral
and
reverse switch to normal.
~k\f your transmitter
is
capable
of
programmed settings such
as
ABS
or acceleration function, turn
off all
settings.
)Tum on receiver. When installing for
the first
time,
LED light will flash
red
once.
(3) Push
set
button once with throttle
trigger in neutral.
^Transmitter
throttle
trigger
Push
set button
(for
more than
0.5
sec).
® Pull throttle trigger to maximum ac-
celeration
and
push
set
button
once.
LED
flashes
red.
Maximum
acceleration
©Push throttle trigger
to
maximum
reversing and push set button once.
<3>
LED
changes
to
a
double
flash.
Maximum
reversing
(Full-braking)
Push
once.
<3>
LED
turns
off.
(§)
Setting
completed.
(Standard settings)
^Throttle positioning must be set in this sequence and can not
be
set individually.
•*-lf power
is
turned
off
before completion, the new settings will
be
lost
and
old
throttle positioning will remain.
^r/Until
you correctly complete the
step,
you can not progress to the
next
one.
lk"You must set new throttle positioning when changing transmitters.
Turning reverse function
off
-ArAllows you
to
enter races forbidding reverse running. Follow the
instructions below
to
turn reverse function
off
(pushing throttle
trig-
ger
will
activate brakes only).
^Follow same sequence
to
turn reverse function on (switches be-
tween
on
/
off setting each time done).
Turn on transmitter.
Turn
on receiver while holding down the set but-
ton,
then release button immediately (within
3
sec.). Flashing LED
quickly flashes red twice and turns
off
(only flashes once when
turn-
ing
reverse
function
on).
Setting completed.
#
* # -
»
-^Checking
if
reverse
function is on or off.
When reverse function
is
on: LED will flash red once when turning
on transmitter
and
then receiver.
*
When reverse function
is
off: LED will flash red twice when turning
on transmitter
and
then receiver.
Default setting
•ArCancels all changes and returns to original settings at time
of
pur-
chase.
Turn on transmitter.
Turn
on receiver while holding down the set but-
ton.
Keep holding down button until flashing
red
light turns green
(app.
3
sea).
Release button.
LED light will
be
green
for 2
sec., then turn
off.
Default setting
is
completed.
More
than 3
sec.
<S>
Green
light
(for
2
sec.).
Green
$fc $fe $fc
