TCL Air Conditioner Service Manual
4
Technical Specifications
Model No. TAC-12CSA/M TAC-12CHSA/M TAC-18CSA/M TAC-18CHSA/M
Type Cooling Only Heating Pump Cooling Only Heating Pump
Control type Remote Remote Remote Remote
Rated cooling capacity Btu/h 12,000 12,000 18,000 18,000
Rated heating capacity Btu/h N/A 1,3500 N/A 19,000
EER for cooling Btu/h.w 10.6 10.6 9.4 9.4
COP for heating W/W N/A 3.5 N/A 3.1
Moisture removal Liters/h 1.27 1.27 2.0 2.0
High dB(A) 38 38 42 42
Med. dB(A) 34 34 38 38
Indoor noise level at
cooling
Low dB(A) 32 32 36 36
Outdoor noise level dB(A) 55 55 58 58
Electrical Data
Power supply 220V~/50Hz
Voltage Range V
Cooling A 5.2 5.2 8.7 8.7
Rated current
Heating A N/A
5.2 N/A 8.2
Cooling W 1130 1130 1900 1900
Rated input
Heating W N/A
1120 N/A 1800
Refrigerating System
Refrigerant/Charge Gram R410A/1240g R410A/1240g R410A/1450g R410A/1450g
Type Rotary Rotary Rotary Rotary
Model ------------------ ----------------- ------------------ ------------------
LRA A ------ ------- ------ ------
Compressor
MFG ----------------- ----------------- ---------------- -----------------
Evaporator Louver fin and Grooved tube type (φ7)
Condenser Corrugated fin and Grooved tube type (φ9.53)
Expansion device Capillary tube
Defrosting system Microcomputer controlled reverse system
Fan System
Indoor air circulation m
3
/h 530 530 800 800
Indoor fan type Cross flow Cross flow Cross flow Cross flow
Cooling rpm 1250/1150/1050 1250/1150/1050 1060/970/880 1060/970/880
Heating rpm N/A 1200/1100/1000 N/A 1060/970/880
Dry rpm 1050 1050 880 880
Indoor fan speed
H/M/L
Sleep rpm 1050 1050/1000 880 880
Indoor fan motor output W 12 12 12 12
Outdoor air circulation m
3
/h --- --- --- ---
Outdoor fan type Propeller fan Propeller fan Propeller fan Propeller fan
Outdoor fan speed rpm 860 860 850 850
Outdoor fan motor output W 31 31 31 31
Connections
Refrigerant coupling Flare type
Gas Inches 1/2 1/2 1/2 1/2
Connecting Pipe
Liquid Inches 1/4 1/4 1/4 1/4
Connecting Wiring
Size × Core
number
Drainage Pipe O.D 16mm
Others
Suitable area m
2
16~28 16~28 30~40 30~40
Indoor mm 785×260×195 785×260×195 1036×313×204 1036×313×204 Net dimensions
(W x H x D)
Outdoor mm
760×552×256 760×552×256 760×540×255 760×540×255
Indoor kg 9.0 9.0 14.0 14.0
Net weight
Outdoor kg
33 34 48 48
Indoor mm 860×330×270 860×330×270 1103×395×280 1103×395×280Packing dimensions
(W x H x D)
Outdoor mm
848×361×600 848×361×600 863×376×605 863×376×605
Indoor kg 10 10 17 17
Gross weight
Outdoor kg 37 38 51 52
Loading Capacity 40’/40’HC 110/235/265 110/235/265 90/188/218 90/188/218
