TCL Air Conditioner Service Manual
38
9.Disassemblytheevaporator
A.Unfix2screwsofleftsideshownas
picture.
B.Unfix2screwsofrightsideonmotor
cover/rightsupportplate.
C.Taketheevaporatoroutfromunitby
uplifting the IUPUT/OUTPUT pipes
slightly.
螺钉
螺钉/卡扣
10.RemovetheMOTORCOVER
Unfix4screwsonthemotorcoverwith
baseframe.
螺钉
11.Disassemblyfanmotorandfanblade.
A. Uplift the fan blade and fanmotor,
takethebaseframeout.
B.Unfixonescrewontheaxisoffan
motor, and you can get fan blade and
fanmotorseparately.
螺钉
screws Screws+motor
cover
screws
screw
