Tektronix MSO54 Declassification And Security Instructions

Type & min.
size
Function Type of user
info stored
Method of
modification
Data Input
method
Location User
accessible
To clear To sanitize
EEPROM
≥2 Kbit
Holds AFG
calibration
data
None Indirect Factory
operations
AFG riser
board
No Not
applicable,
does not
contain user
data or
settings.
Clearing
would disable
instrument
functionality.
Not
applicable,
does not
contain user
data or
settings.
Sanitizing
would disable
instrument
functionality.
EEPROM
≥64 Kbit
Holds the
front panel
USB
configuration
None None Factory
operations
Front panel
LED board
No Not
applicable,
does not
contain user
data or
settings.
Clearing
would disable
instrument
functionality.
Not
applicable,
does not
contain user
data or
settings.
Sanitizing
would disable
instrument
functionality.
EEPROM ≥1
Kb
depending on
model
Holds the
SODIMM
memory
configuration
data (SPD)
None None Factory
operations
Module
socket
(SODIMM) on
processor
module board
and module
socket
(SODIMM) on
acquisition
board
No Not
applicable,
does not
contain user
data or
settings.
Clearing
would disable
instrument
functionality.
Not
applicable,
does not
contain user
data or
settings.
Sanitizing
would disable
instrument
functionality.
Flash
Memory
≥16 Mbit
Two pieces
Holds a
portion of the
Acquisition
FPGA
configuration
None Indirect Application
software
operations
Acquisition
board
No Not
applicable,
does not
contain user
data or
settings.
Clearing
would disable
instrument
functionality.
Not
applicable,
does not
contain user
data or
settings.
Sanitizing
would disable
instrument
functionality.
Table continued…
Clear and sanitize procedure
5 Series and 6 Series B Mixed Signal Oscilloscopes Declassification and Security Instructions 9
