TOHATSU MFS 9.9 User Manual

1 Intake Valve 2 Intake valve diameter: 25mm
2 Exhaust Valve 2 Exhaust valve diameter: 24mm
3 Intake Valve Stem Seal 2 Black
4 Exhaust Valve Stem Seal 2 Green
5 Valve Spring 4 L=35
6 Valve Spring Seat 4
7 Retainer 4
8 Cotter 8
9 Rocker Arm (t=17) 4
10 Adjusting Screw 4
Description
Remarks
Q'ty
5
5-9
4st 9.9/15/20 2008
7 N·m (5 lb·ft) [0.7 kgf·m]
7 N·m (5 lb·ft) [0.7 kgf·m]
7 N·m (5 lb·ft) [0.7 kgf·m]
4st OIL
4st
OIL
4st OIL
4st
OIL
4st OIL
4st
OIL
4st OIL
4st
OIL
4st OIL
4st
OIL
4st OIL
4st
OIL
4st OIL
4st
OIL
11
10
16
9
8
8
7
5
6
3
1
11
10
14
13
9
15
12
11
10
13
14
10
11
13
9
9
8
8
7
5
6
4
2
12
14
Intake Valve & Exhaust Valve P/L Fig. 7
4st
OIL
4st OIL
Ref.
No.
11 Adjusting Nut 4
12 Rocker Arm Shaft 2
13 Collar, 13.1-15.9-22.5 3
14 Rocker Shaft Spring 3 L=30
15 Rocker Shaft Spring 1 L=51
16 Washer, 13.2-21.7-2 1
Ref.
No.
Description Remarks
Q'ty
E_MFS20C_ch05_090105.qxd 09.1.20 5:25 PM ページ 9
