3-13
3
4st 9.9/15/20 2008
4. Loosen flywheel nut 3.
12) Replacement of Timing Belt
1. Disconnect starter lock cable 1.
Apply forces to tools toward directions as
shown, and perform work taking care not to
allow flywheel holder to remove.
Flywheel Puller Kit :
P/N. 369-72211-0
1
3. Rotate flywheel 1 clockwise to bring "●1" mark a of cam
shaft pulley 2 to "▲" mark b of cylinder head.
#1 piston is to be at top dead center of compression
stroke.
2. Remove recoil starter, belt cover and starter pulley.
