4
Using the Cutting-Unit Kickstand
Parts Required
1 Cutting-unit kickstand
G402676
1. When tipping a cutting unit to expose the
bedknife/reel, prop up the rear of the cutting
unit with the kickstand
to ensure that the
nuts on the back end of the bedbar adjusting
screws are not resting on the work surface.
G402677
2. Secure the kickstand to the chain bracket
with the snapper pin .
5
Applying the Production Year Decal
Parts Required
1 Production year decal
3464-490A Page 3–12 Setup: Using the Cutting-Unit Kickstand
