Toro Groundsmaster 360 Service Manual

UsingtheInfoCenterDisplayforTroubleshooting(continued)
IntheDecksoperationexample,thefollowingqualiersmustbeinthe
desiredcondition(
)beforeanyoperationOutputscanbeenergized:
•Operatormustbeinseat(seatswitch)
•ParkingbrakeOFF
Ifanddonotalternatewhenthequalierconditionischanged,the
qualierorthecircuitwiringforthequalierisdamagedandshouldbetested
asdescribed.
8.Pressthemenu/backbutton(asindicatedbythe
atthebottomofthe
screen).Select(highlight)theOutputsandpresstheleft/rightbutton(as
indicatedbythe
atthebottomofthescreen).
9.IfalltheInputsareONandalltheQualiersareintheirdesiredcondition(
),
theOutputsforthemachineoperationshouldbeON.Iftheoutputsremain
OFF,theToroElectronicController(TEC)orTECsoftwaremaybedamaged
andrequirereloadingorreplacement.ContactyourToroDistributorfor
assistance.
10.IftheoutputslistedontheInfoCenterDisplayareON,andtheoperation
isstillmalfunctioning:
•Testthespecicoutputandoutputwiring;refertoTestingtheElectrical
Components(page5–49).
•T estthehydrauliccomponentsrelatedtotheoperation;refertoChapter
4:HydraulicSystem(page4–1).
IntheDecksoperationexample,theoutputsarethesolenoidvalveSV1
forcuttingdeckraiseandsolenoidvalveSV2forcuttingdeckoat.IfON
appearsnexttotheseoutputsontheInfoCenterDisplay:
•T estthehydraulicsolenoidvalvecoils;refertoHydraulicSolenoidValve
Coils(page5–91).
•Performcuttingdeckhydrauliccircuittests;refertoChapter4:Hydraulic
System(page4–1).
Groundsmaster360
Page5–33
ElectricalSystem:Troubleshooting
16225SLRevC
