CabControls
g028431
Figure7
1.Air-recirculationcontrol5.Poweroutlet
2.Fancontrol6.Lightsswitch
3.Temperaturecontrol7.Flashersswitch
4.Windshield-wiperswitch8.Air-conditioningswitch
AirRecirculationControl
Setsthecabtoeitherrecirculatetheairinthecabinor
todrawairintothecabinfromoutside(Figure7).
•Setittorecirculatetheairwhenusingtheair
conditioning.
•Setittodrawairinwhenusingtheheaterorfan.
Fan-ControlKnob
Rotatethefan-controlknobtoregulatethespeedof
thefan(Figure7).
Temperature-Control-Knob
Rotatethetemperature-controlknobtoregulatethe
airtemperatureinthecab(Figure7).
Windshield-WiperSwitch
Usethisswitchtoturnthewindshieldwipersonor
off(Figure7).
Air-ConditioningSwitch
Usethisswitchtoturntheairconditioningonoroff
(Figure7).
PowerOutlet
Usethis15A,12VDCpoweroutlettopower
compatibledevices(Figure7).
LightsSwitch
Usethisswitchtoturntheheadlightsandtaillighton
oroff(Figure7).
FlashersSwitch
Usethisswitchtoturntheashers(hazardlights)on
oroff(Figure7).
WindshieldLatch
Liftupthelatchestoopenthewindshield(Figure8).
PressinthelatchtolockthewindshieldtotheOPEN
position.Pulloutanddownonthelatchtocloseand
securethewindshield.
g196911
Figure8
1.Windshieldlatch
RearWindowLatch
Liftupthelatchestoopentherearwindow.Pressin
onthelatchtolockthewindowinOPENposition.Pull
outanddownonthelatchtocloseandsecurethe
window(Figure8).
Important:Closetherearwindowbeforeopening
thehoodordamagemayoccurtothehoodorrear
window.
19
