Lubrication
GreasingtheSprayPump
ServiceInterval:Every50hours—Lubricatethe
pump.
Every50hours/Yearly(whichevercomesrst)
GreaseType:MobilXHP461.
1.Wipethe2remotegreasettingclean(Figure
67).
g204693
Figure67
1.Backofthemachine3.Greasepoint(2)
2.Spraypump
2.Pumpgreaseintotheremotegreasetting
(Figure67).
3.Wipeofftheexcessgrease.
GreasingtheFrontSteering
andSuspension
ServiceInterval:Every50hours—Lubricatethe
pump.
Every50hours/Yearly(whichevercomesrst)
GreaseType:No.2lithiumgrease.ToroPremium
All-PurposeGreaseisavailablefromyourT oro
Distributor.
•Steeringcylinder—2greasettingsateachrod
endofthecylinder
•Steeringrod—2greasettingsateachrodend
•Spindlepivot—2greasettingsateachsideofthe
machine
1.Wipethegreasettingsclean(Figure68and
Figure69).
2.Pumpgreaseintothegreasettings(Figure68
andFigure69).
3.Wipeoffexcessgrease.
Note:Thegreasettingspositionsare
illustratedinFigure68.
g187456
Figure68
1.Greasetting
g187457
Figure69
Thereare2ttingsateachfrontwheel.
1.Greasettings
GreasingtheBoomHinges
ServiceInterval:Every100hours
Important:Iftheboomhingeiswashedwith
water,clearallwateranddebrisfromthehinge
assemblyandfreshgreasemustbeapplied.
GreaseType:No.2lithiumgrease.
1.Wipethegreasettingscleansothatforeign
mattercannotbeforcedintothebearingor
bushing.
2.Pumpgreaseintothebearingorbushingat
eachtting(Figure70).
53
