g238948
Figure87
1.Fillplug
3.Checkplug
2.Fill-plughole(planetary
lubricant)
5.ChecktheO-ringsofthellplugforthedamage.
IftheO-ringisdamaged,replaceit.
6.Installthellplugandthecheckplug(Figure87).
7.Repeatsteps1through6fortheplanetary-gear
driveattheothersideofthemachine.
Changingthe
Planetary-Gear-Drive
Lubricant
ServiceInterval:Aftertherst8hours
Every400hoursoryearly,whichevercomes
rst.
DrainingthePlanetary-Gear-Drive
Lubricant
1.Withthemachineonalevelsurface,positiona
wheelsothatthellplugisatthehighest(12
o’clock)positionandthedrainplugisatthe
lowest(6o'clock)position;refertoFigure85in
CheckingthePlanetary-Gear-DriveLubricant
(page65).
2.Placeadrainpanunderthehubofthe
planetary-geardrive,removethedrainplug,ll
plug,andthecheckplug,andallowthelubricant
todraincompletely(Figure88).
g238951
Figure88
1.Fillplug
4.Drain-plughole(planetary
lubricant)
2.Fill-plughole(planetary
lubricant)
5.Drainplug
3.Check-plughole
(planetarylubricant)
6.Checkplug
3.Examinethedrainandllplugsformetal
shavings.
Iflldrainandllplugsarecoveredwithmetal
shavings,repairtheplanetary-geardrive.
4.ChecktheO-ringsofthedrainplug,llplug,and
thecheckplugforthedamage.
IftheO-ring(s)isdamaged,replaceit.
5.Installthedrainplug.
6.Placeadrainpanunderthebrakehousing,
removethedrainplug,andallowthelubricantto
draincompletely(Figure89).
g238950
Figure89
1.Drainhole(brakehousing)
2.Drainplug
7.Installthedrainpluginthebrakehousing.
66
