Important:Onlyengagethepumpswitchwhenthe
engineisatlowidletoavoiddamagingthepumpdrive.
AgitationSwitch
Theagitationswitchislocatedonthecontrolpaneltothe
rightoftheseat(Figure15).Togglethisswitchforwardto
turnontheagitationinthetankorrearwardtostopthe
agitation.Whentheswitchisturnedon,alightontheswitch
illuminates.Tooperatetheagitationfunction,youmustrun
thesprayersystempumpandyoumustruntheengineabove
anidle.Theagitationvalveislocatedbehindthetank(Figure
16)
Figure16
1.Actuator(agitationvalve)3.Handle(agitationbypass)
2.Handle(agitationthrottle
valve)
AgitationBypassValve
Theagitationbypassvalveredirectstheowofuidtothe
sprayersystempumpwhenyouturnofftheagitationfunction
(Figure16).Theagitationbypassvalveislocatedattheabove
oftheagitationvalve.Youcanadjustthebypassvalveto
ensurethatpressureremainsconstantduringagitation;refer
toCalibratingtheAgitationBypassValve(page35).
AgitationThrottleValve
Theagitationthrottlevalveisamanuallyoperatedballvalve
thatcontrolsowtotheagitationnozzlesinthemaintank
(Figure16).Usingthisvalveallowstheusertocontrolthe
sprayersystempressureattheagitationnozzlesofthemain
tankwhenlargerapplicationratesarerequired.
SectionValves
Thesectionvalvescontrolowtothe3boomsections
(Figure17).Ifyoueverneedtomanuallyturnoffasection,
rotatetheknobonthevalveclockwisetoturnthevalveoffor
counterclockwisetoturniton.
Note:Turningthesectionvalvemanuallycaninterferewith
thefunctionofthefuses.Thefusesshouldbecheckedafter
manuallyrotatingthevalve.
Figure17
1.Knob(sectionbypass
valve)
2.Actuators(sectionvalve)
Anti-siphonFillReceptacle
Tothefrontofthetankcoverisahosereceptaclewitha
threadedtting,a90-degreebarbedtting,andashorthose
whichyoucandirecttowardthetankopening.Thisreceptacle
allowsyoutoconnectawaterhosetoitandllthetankwith
waterwithoutcontaminatingthehosewiththechemicalsin
thetank.
Important:Donotlengthenthehosetoallowcontact
withthetankuids.Thedistancefromtheendofthe
hosetotheuppermostwaterlevelshouldbewithinlocal
regulatorylimits.
G013787
1
2
Figure18
1.Anti-siphonllreceptacle
2.Tankcover
20
