Toro TimeCutter Z5000 74391 User Manual

G005278
1
2
2
3
3
4
4
Figure40
1.Bladessidetoside
3.Outsidecuttingedges
2.Sailareaofblade
4.Measurehere
6.Measurebetweentheoutsidecuttingedgesand
theatsurface(Figure40).Ifbothmeasurements
arenotwithin3/16inch(5mm),anadjustmentis
required;continuewiththisprocedure.
7.Attheleftsideofthemachine.Loosen,butdonot
remove,therearlockingnutonthehangerbracket
(Figure41).
8.Loosenthesidelockingnutonthehangerbracket
justenoughtoallowthecentricplatetobeadjusted
(Figure41).Usea3/8inchdriveextensionona
socketwrenchtomanipulatethecentricplate.Use
thewrenchtorepositiontheheightofthemower
deckandadjusttothedesiredheight.
9.Stopthedeckattheadjustedpositionandtighten
thesidelockingnutonthehangerbrackettohold
thenewposition(Figure41).
10.Continuelevelingthedeckbycheckingthe
front-to-rearbladeslope;refertoAdjustingthe
Front-to-RearBladeSlope.
3
G005074
1
2
3
4
5
6
Figure41
1.Hangerbracket
4.Centricadjustmentplate
2.Rearlockingnut
5.Socketwrenchhole
3.Sidelockingnut6.Socketwrenchwith3/8
inchextension
AdjustingtheFront-to-Rear
BladeSlope
Checkthefront-to-rearbladelevelanytimeyouinstall
themower.Ifthefrontofthemowerismorethan
5/16inch(7.9mm)lowerthantherearofthemower,
adjustthebladelevelusingthefollowinginstructions:
1.Parkthemachineonalevelsurfaceanddisengage
thebladecontrolswitch.
2.Movethemotioncontrolleversoutwardtothe
parkposition,stoptheengine,removethekey,and
waitforallmovingpartstostopbeforeleavingthe
operatingposition.
3.Checktheairpressureofallfourtires.Ifneeded,
adjusttotherecommendedination;referto
CheckingtheTirePressureinDriveSystem
Maintenance,page30.
4.Checkandadjusttheside-to-sidebladelevelifyou
havenotcheckedthesetting;refertoLevelingthe
MowerfromSide-to-Side.
5.Settheheight-of-cutatpositionD[3inch(76mm)]
andcarefullyrotatethebladessotheyarefacing
fronttorear(Figure42).
33

Toro TimeCutter Z5000 74391 Specifications

General

Cutting Width	50 inches
Transmission	Hydrostatic
Deck Material	10-gauge steel
Number of Blades	3
Type	Zero-Turn Mower
Speed	7 mph forward, 3 mph reverse
Cutting Height	1.5 - 4.5 inches
Warranty	3-year limited
Fuel Capacity	3 gallons
