CheckingtheMachinefor
Grease
Partsneededforthisprocedure:
1tube
No.2lithiumormolybdenum-basedgrease(purchase
separately)
Procedure
Beforeyouusethemachine,checkthemachineforgrease;
refertoLubricationintheOperator'sManual.
10
InstallingtheRightBumper
Partsneededforthisprocedure:
3
Locknut(3/8inch)
3
Carriagebolt(3/8x2-1/4inches)
Procedure
Mountthesidebumpersinthetopholeswhenoperatingin
heightofcuthigherthan64mm(2-1/2inches)andinthe
centerholeswhenoperatinginheightofcutlowerthan64
mm(2-1/2inches).
1.Raisethemowerdecktothe12.7cm(5inch)height
position(alsothetransportposition).
2.Therightbumperisziptiedtothemachinefor
shipping.Removeanddiscardtheplasticzipties.
Figure5
1.Carriagebolt
2.Bumper(center-holemountingshown)
3.Locknut
3.Moveeachbumpertothedesiredpositionandsecure
itwith3carriagebolts(3/8x2-1/4inches)and3
locknuts(3/8inch).
4.Torquetheboltsto14to16N∙m(10to12ft-lb).
