IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
CAUTION
CAUTION
WARNING
WARNING
Misuse of this equipment could result in human injury and equipment
damage. In no event will Toshiba Corporation be responsible or liable for
either indirect or consequential damage or injury that may result from theuse of this equipment.
Do not dispose of the batteries in a fire. The batteries may explode.
This unit contains sealed lead acid batteries. Lack of preventative
maintenance could result in batteries exploding and emitting gasses
and/or flame. Annual preventative maintenance must be performed by an authorized, trained technician.
Failure to replace a battery before it becomes exhausted may cause
the case to crack, possibly releasing electrolytes from inside the
battery, and resulting in secondary faults such as odor, smoke, and fire.
This manual contains important instructions
for 2.4, 3.6, 6.0, and 8.0 kVA units that should
be followed during the installation and use of the UPS and it's batteries.
Hardwire type UPS units are not equipped with an overcurrent-protection device, nor an output disconnect
for the ac output. Therefore, a circuit breaker should be provided by the user between the UPS output and
the load input. This device should be rated as follows:
2.4 kVA: 220 or 240/208 Vac, 15A
3.6 kVA: 220 or 240/208 Vac, 20A
6 kVA: 220 or 240/208 Vac, 30A
8 kVA 240/208 Vac, 40A
The maximum ambient temperatures in which the UPS units should be operated are as follows:
2.4 kVA: 104° F (40° C).
3.6 kVA: 104° F (40° C).
6 kVA: 104° F (40° C).
8 kVA 104° F (40° C).
The nominal battery voltages for these models are as follows:
2.4kVA: 96Vdc
3.6kVA: 144Vdc
6 kVA: 216Vdc
8 kVA 252Vdc
Servicing of the batteries should only be performed by a qualified Toshiba Representative who is
knowledgeable of batteries and the required precautions. Keep unauthorized personnel away from
batteries.
When having batteries replaced, use the same number and type of one of the following sealed, lead-acid
batteries:
Model Capacity Manufacturer Type Quantity
2.4 kVA Panasonic LCV 12V-7.2P 8
Yuasa NP7-12FR 8
3.6 kVA Panasonic LCV 12V-7.2P 12
Yuasa NP7-12FR 12
6 kVA Panasonic LCV 12V-7.2P 18
Yuasa NP7-12FR 18
8 kVA Panasonic LCV 12V-7.2P 21
Yuasa NP7-12FR 21
NPX-35FR (9Ah) 21
