79
4400 Series Installation and Operation Manual – 64527-008
12.8 Quick Access Toolbar
The Quick Access Toolbar allows the operator easily perform routine commands. The Quick Access Toolbar buttons and
their function are listed below.
TABLE 12.2: QUICK ACCESS TOOLBAR CONTROLS
Quick Access Toolbar Controls
Icon Function
Security/Access Level – Access levels are: USR, ADM
Warning Buzzer mute. Press to silence buzzer. Buzzer will sound again at
next fault event. (To silence buzzer for all fault events set to “Disable”.)
Touch Screen ON/OFF button. Press to toggle between ON and OFF.
• ON enables all touchscreen active areas.
• OFF disables all touchscreen areas except the TOUCH button.
Quick View On/O Selector – Press to toggle between Normal view and Quick
view. Quick view displays a simultaneous summary of the Input/Output/
Bypass/DC Voltages and Currents
See Section 12.12.
