Toshiba B-EV4 Series User Manual

- 172 -
6.3.31 PRINTER INFORMATION STORE COMMAND [ESC] IG
Function Sets the printer information.
Format [ESC] IG; aaa --- aaabbb --- bbb [LF] [NUL]
Term aaa --- aaa: Model name (Fixed as 20 digits)
20H to 7FH of ASCII codes
bbb --- bbb: Serial No. (Fixed as 11digits)
20H to 7FH of ASCII codes
Explanation (1) The model name and serial No. of the printer can be optionally stored. The
character codes which can be set in each item are 20H to 7FH. If any code
other than these is used, it is replaced with the space code.
(2) The printer information has already been set when shipped.
(3) The stored printer information is backed up in memory and is kept even if the
power is turned off.
(4) This stored information should be printed on test print.
Examples The following information is stored in the printer.
Model name: B-EV4D-GS14-QM-R
Serial No.: 2303A000001
[ESC] IG; [42H] [2DH] [45H] [56H] [34H] [44H] [2DH] [47H] [53H] [31H] [34H] [2DH] [51H] [4DH] [2DH]
[52H] [20H] [20H] [20H] [20H] [32H] [33H] [30H] [33H] [41H] [30H] [30H] [30H] [30H] [30H]
[31H] [LF] [NUL]
Refer to Printer Information Request Command ([ESC] IR)

Toshiba B-EV4 Series Specifications

General

Print Method	Direct Thermal / Thermal Transfer
Power Supply	AC 100-240V, 50/60 Hz
Operating Temperature	5°C to 40°C
Print Resolution	203 dpi, 300 dpi
Max Print Speed	Up to 127 mm/sec (5 ips) (203 dpi) / Up to 101.6 mm/sec (4 ips) (300 dpi)
Interface	USB, Serial
Optional Interfaces	Wireless LAN
Weight	2.4 kg
Barcodes	Code 39, Code 128
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code
Media Width	25.4 mm to 112 mm
Media Thickness	0.06 mm to 0.19 mm
Media Roll Diameter	Max. 127 mm
Ribbon Width	40 mm to 110 mm
Ribbon Length	300 m
Operating Humidity	25% to 85% non-condensing
