Hydro Unit
Installation Manual
EN
1 General information
System combination
General specifications
Outdoor Unit
Single Phase model
3 Phase model
Outdoor Unit
Hydro Unit
HWS-
455H-E
HWS-
805H-E
HWS-
1105H-E
HWS-
1405H-E
HWS-
1105H8-E
HWS-
1405H8-E
HWS-
1605H8-E
HWS-
1105H8R-E
HWS-
1405H8R-E
HWS-
1605H8R-E
Backup
heater
HWS-455XWHM3-E ––––––– – –~, 3 kW
HWS-805XWHM3-E – –––––– – –~, 3 kW
HWS-805XWHT6-E – –––––– – –3N ~, 6 kW
HWS-805XWHT9-E – – – – – – – – 3N~, 9 kW
HWS-1405XWHM3-E
–– ~, 3 kW
HWS-1405XWHT6-E – – 3N~, 6 kW
HWS-1405XWHT9-E – – 3N~, 9 kW
220-230 V model 3 phase model 3 phase with Cord Heater
Outdoor unit HWS-455H-E HWS-805H-E HWS-1105H-E HWS-1405H-E
Power supply 220-230 V ~ 50 Hz
Type INVERTER
Function Heating & Cooling
Heating
Capacity (kW) 4.5 8.0 11.2 14.0
Input (kW) 0.92 1.79 2.30 3.11
COP (W/W) 4.90 4.46 4.88 4.50
Cooling
Capacity (kW) 4.5 6.0 10.0 11.0
Input (kW) 1.46 1.94 3.26 3.81
EER (W/W) 3.08 3.10 3.07 2.89
Refrigerant R410A
Dimension HxWxD (mm) 630x800x300 890x900x320 1,340x900x320
Outdoor unit
with Cord heater
HWS-
1105H8-E
HWS-
1405H8-E
HWS-
1605H8-E
HWS-
1105H8R-E
HWS-
1405H8R-E
HWS-
1605H8R-E
Power supply 380-400 V 3N~ 50 Hz
Type INVERTER
Function Heating & Cooling
Heating
Capacity (kW) 11.2 14.0 16.0 11.2 14.0 16.0
Input (kW) 2.34 3.16 3.72 2.34 3.16 3.72
COP 4.804.444.304.804.444.30
Cooling
Capacity (kW) 10.0 11.0 13.0 10.0 11.0 13.0
Input (kW) 3.26 3.81 4.80 3.26 3.81 4.80
EER 3.07 2.89 2.71 3.07 2.89 2.71
Refrigerant R410A
Dimension HxWxD (mm) 1,340x900x320
Cord heater (W) – 75
2-EN
