’03 Rav4_U (L/O 0208)
149
2003 RAV4 from Aug. ’02 Prod. (OM42517U)
(b) Behind the front seats
(folding up rear seats)
3. Fold up the rear seat cushions and
hook the claw of the strap over the
rear hinge of the rear seat. (See
“—Folding up rear seats” on page 34
in Section 1–3.)
(c) Behind the front seats
(removing rear seats)
3. Remove the rear seats and hook the
claw of the strap over the front
hinge of the rear seat as shown
above. (See “—Removing rear seats”
on page 37 in Section 1–3.)
4. Pull the end of the belt to stretch
the net securely.
Make sure the net does not interfere
with a reclined seatback or head re-
straint.
CAUTION
When not using the separation net,
make sure that the cover of the fixing
hook is closed. If the cover is open,
it might cause the unexpected injury
like hitting a head.
To Next Page
