When driving

2-2. Gauges and meters

Gauges and meters

The following gauges, meters and displays illuminate when the

engine switch is in the ON position.

Tachometer

Displays the engine speed in revolutions per minute.

Speedometer

Displays the vehicle speed.

Engine coolant temperature gauge

Displays the engine coolant temperature.

Fuel gauge

Displays the quantity of fuel remaining in the tank.

ODO/TRIP button

Switches between odometer and trip meter displays. Pushing and hold-

ing the button will reset the trip meter when the trip meter is being dis-

played.
