Troubleshooting Guide VESTroubleshooting Guide VESTroubleshooting Guide VESTroubleshooting Guide VESTroubleshooting Guide VESTroubleshooting Guide VESTroubleshooting Guide IN-CAR ENTERTAINMENT SYSTEM
6
06-04
Note: For the voltage check of *A-*L, please see connector assignment table on pages 17 & 18.
Are audio +B and the ACC
circuit fuse normal?
Are the fuses in the
ICE harness normal?
YES
Is power supplied from the
vehicle’s audio harness?
YES
YES
REPLACE THE FUSES.
REPLACE THE FUSES.
REFER TO THE VEHICLE’S
REPAIR DOCUMENT.
NO
NO
NO
D
Is power supplied to the
4P filter connector?
Is power supplied to the
6P filter connector?
YES
REPLACE THE
ICE MAIN HARNESS.
YES
REPLACE THE POWER HARNESS
WITH FUSES.
REPLACE THE FILTER.
NO
NO
K
I
L
J
