TP-Link AC1200 User Manual

3
Chapter 1
Get to Know About Your Router
LED Explanation
Name Status Indication
Power
On Power is on.
Flashing
The system is starting up or the firmware is being upgraed. Do
not disconnect or power off your router.
Off Power is off.
2.4GHz
On The 2.4GHz wireless band is enabled.
Off The 2.4GHz wireless band is disabled.
5GHz
On The 5GHz wireless band is enabled.
Off The 5GHz wireless band is disabled.
Internet
On Internet connection is available.
Off No Internet connection.
LAN
On A device is connected to the LAN port.
Off No device is connected to the LAN port.
USB
On The inserted USB device is ready to use.
Flashing A new USB device is being identified.
Off No USB device is plugged into the USB port.
WPS
On/Off
Turns on when a WPS synchronization is established and
automatically turns off about five miniutes later.
Flashing
A Wireless device is trying to connecet to the network via WPS.
This process may take up to 2 minutes.

TP-Link AC1200 Specifications

General

Type	-
Windows operating systems supported	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Wi-Fi data rate (max)	867 Mbit/s
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 30 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Ethernet LAN (RJ-45) ports	1
Power consumption (typical)	9 W
Antennas quantity	3
Antenna gain level (max)	3 dBi
Sustainability certificates	RoHS

Weight and Dimensions

Depth	125 mm
Width	202 mm
Height	86 mm
