Trane 4TTX6 User Manual

6 18-AC55D1-4
Installer’s Guide
4TTX6 OUTLINE DRAWING
NOTE: ALL DIMENSIONS ARE IN MM (INCHES).
From Dwg. D152635 Rev. 11
MODELS BASE A B C D E F G H J K
4TTX6024B 3 1118 (44) 829 (32-5/8) 756 (29-3/4) 5/8 5/16 143 (5-5/8) 92 (3-5/8) 210 (8-1/4) 79 (3-1/8) 692 (27-1/4)
4TTX6036B 4 1064 (41-7/8) 946 (37-1/4) 870 (34-1/4) 3/4 3/8 152 (6) 98 (3-7/8) 219 (8-5/8) 86 (3-3/8) 730 (28-3/4)
4TTX6048B 4 1267 (49-7/8) 946 (37-1/4) 870 (34-1/4) 7/8 3/8 152 (6) 98 (3-7/8) 219 (8-5/8) 86 (3-3/8) 730 (28-3/4)
4TTX6060B 4 1267 (49-7/8) 946 (37-1/4) 870 (34-1/4) 7/8 3/8 152 (6) 98 (3-7/8) 219 (8-5/8) 86 (3-3/8) 730 (28-3/4)
