Trane 4TVS0007DF000A User Manual

Floor standing indoor unit with DC fan motor
10
Horsepower set
ENC1 switch code Cooling power output
0 2200W(0.8HP）
1 2800W(1.0HP）
2 3600W(1.2HP）
3 4500W(1.5HP）
4 5600W(2.0HP）
5 7100W(2.5HP）
6 8000W(3.0HP）
Note: Base on different purposes to setting the switch cords on PC panel of indoor electrical control box. Once finish the
setting, please cut off the main power, and then input power again, otherwise, setting function could not work.
Main board Code designation
SW1 definition
SW2 definition
