Trane RTHD User Manual

RLC-PRC020-EN18
Minimum/Maximum Evaporator Flow Rates (GPM)
Two Pass Three Pass Four Pass
Evaporator Nominal Nominal Nominal
Code Min Max Conn Size (In.) Min Max Conn Size (In.) Min Max Conn Size (In.)
B1 303 1104 8 200 736 6 —- —- —-
B2 346 1266 8 233 844 6 —- —- —-
C1 346 1412 8 254 941 6 —- —- —-
C2 375 1531 8 276 1022 6 —- —- —-
D1 498 1812 8 330 1206 8 —- —- —-
D2 541 1980 8 357 1320 8 —- —- —-
D3 584 2131 8 389 1417 8 —- —- —-
D4 422 1542 8 281 1028 8 —- —- —-
D5 422 1542 8 281 1028 8 —- —- —-
D6 352 1287 8 233 860 8 —- —- —-
E1 487 1980 8 357 1320 8 —- —- —-
F1 676 2478 10 454 1655 8 —- —- —-
F2 725 2667 10 487 1780 8 —- —- —-
G1 —- —- —- 606 2218 10 454 1666 8
G2 —- —- —- 660 2413 10 492 1807 8
G3 —- —- —- 747 2732 10 557 2050 8
Notes:
1. Minimum flow rates are based on brine solution.
2. All water connections are grooved pipe.
General Data
Minimum/Maximum Evaporator Flow Rates (Liters/Second)
Two Pass Three Pass Four Pass
Evaporator Nominal Nominal Nominal
Code Min Max Conn Size (mm) Min Max Conn Size (mm) Min Max Conn Size (mm)
B1 19 70 200 13 46 150 —- —- —-
B2 22 80 200 15 53 150 —- —- —-
C1 22 89 200 16 59 150 —- —- —-
C2 23 97 200 17 65 150 —- —- —-
D1 31 114 200 21 76 200 —- —- —-
D2 34 125 200 23 83 200 —- —- —-
D3 37 134 200 25 89 200 —- —- —-
D4 27 97 200 18 65 200 —- —- —-
D5 27 97 200 18 65 200 —- —- —-
D6 22 81 200 15 54 200 —- —- —-
E1 28 125 200 23 83 200 —- —- —-
F1 43 156 250 29 104 200 —- —- —-
F2 46 168 250 31 112 200 —- —- —-
G1 —- —- —- 38 140 250 29 105 200
G2 —- —- —- 42 152 250 31 114 200
G3 —- —- —- 47 172 250 35 129 200
Notes:
1. Minimum flow rates are based on brine solution.
2. All water connections are grooved pipe.
Minimum/Maximum Condenser Flow Rates
(GPM)
Two Pass
Condenser Nominal
Code Min Max Conn Size (In.)
B1 230 850 6
B2 255 935 6
D1 230 850 6
D2 255 935 6
E1 350 1280 8
E2 380 1390 8
E3 390 1420 8
E4 295 1080 8
E5 250 910 8
F1 450 1650 8
F2 430 1560 8
F3 460 1700 8
G1 530 1960 8
G2 650 2360 8
G3 710 2600 8
Notes:
1. Minimum flow rates are based on brine solution.
2. All water connections are grooved pipe.
Minimum/Maximum Condenser Flow Rates
(Liters/Second)
Two Pass
Condenser Nominal
Code Min Max Conn Size (mm)
B1 15 54 150
B2 16 59 150
D1 15 54 150
D2 16 59 150
E1 22 81 200
E2 24 88 200
E3 25 90 200
E4 19 68 200
E5 16 57 200
F1 28 104 200
F2 27 98 200
F3 29 107 200
G1 33 124 200
G2 41 149 200
G3 45 164 200
Notes:
1. Minimum flow rates are based on brine solution.
2. All water connections are grooved pipe.
Brine Flow Rates

Trane RTHD Specifications

General

Type	Water-Cooled Chiller
Refrigerant	R-134a
Compressor Type	Helical Rotary (Screw)
Voltage Options	200, 230, 380, 460, 575
Capacity Range	200 - 4000 tons (703 kW - 14, 060 kW)
