Trane RTHD Troubleshoot Manual

32 RLC-SVD05A-EN
Over/Under Voltage
Acceptable tolerance between actual incoming line-to-line voltage and displayed
voltage (on DynaView or TechView) is +\- 3% of reading. The accuracy of the
meter being used to measure the actual line-to-line voltage needs to be added to
this tolerance.
Acceptable tolerance between the Starter module input voltage measurements
listed Tabl e 6 with respect to the displayed line-to line voltage (on DynaView or
TechView) is +\- 3% of reading.
14.4 290
14.9 300
15.4 310
15.9 320
16.3 330
16.8 340
17.3 350
17.8 360
18.3 370
18.8 380
19.3 390
19.8 400
20.3 410
20.8 420
21.3 430
21.8 440
22.3 450
22.8 460
23.3 470
23.8 480
24.3 490
24.8 500
25.3 510
25.7 520
26.2 530
26.7 540
27.2 550
27.7 560
28.2 570
Table 6. Starter Module Input-to-Line Voltage Conversion
Starter Module Input Voltage
J5-1,2
J5-3,4
J5-5,6
(Volt AC)
Incoming Line-to-Line Voltage
(Volt AC)

Trane RTHD Specifications

General

Type	Water-Cooled Chiller
Refrigerant	R-134a
Compressor Type	Helical Rotary (Screw)
Voltage Options	200, 230, 380, 460, 575
Capacity Range	200 - 4000 tons (703 kW - 14, 060 kW)
