Trane TAM7A0C36H31SA User Manual

TAM72
PRODUCT SPECIFICATIONS
MODEL
RATED VOLTS/PH/HZ.
RATINGS 1
INDOOR COIL — Type
Rows — F.P.I.
Face Area (sq. ft.)
Tube Size (in.)
Refrigerant Control
Drain Conn. Size (in.) 2
DUCT CONNECTIONS
INDOOR FAN — Type
Diameter-Width (In.)
No. Used
Drive - No. Speeds
CFM vs. in. w.g.
No. Motors — H.P.
Motor Speed RPM
Volts/Ph/Hz
F.L. Amps
FILTER
Filter Furnished?
Type Recommended
No.-Size-Thickness
REFRIGERANT
Ref. Line Connections
Coupling or Conn. Size — in. Gas
Coupling or Conn. Size — in. Liq.
DIMENSIONS
Crated (In.)
Uncrated
WEIGHT
Shipping (Lbs.) / Net (Lbs.)
*AM7A0A24H21SA
200-230/1/60
See O.D. Specifications
Plate Fin
3 - 14
3.67
3/8
EEV
3/4 NPT
See Outline Drawing
Centrifugal
11 X 8
1
Direct - Variable
See Fan Performance Table
1 - 1/2
Variable ECM
208-230/1/60
3.0
No
Throwaway
1 - 16 X 20 - 1 in.
R-410A
Brazed
3/4
3/8
H x W x D
51.5 x 19.0 x 23.5
49.9 x 17.5 x 21.75
127/116
*AM7A0B30H21SA
200-230/1/60
See O.D. Specifications
Plate Fin
3 - 14
5.04
3/8
EEV
3/4 NPT
See Outline Drawing
Centrifugal
11 X 10
1
Direct - Variable
See Fan Performance Table
1 - 1/2
Variable ECM
208-230/1/60
3.0
No
Throwaway
1 - 20 X 20 - 1 in.
R-410A
Brazed
3/4
3/8
H x W x D
56.5 x 23 x 23.5
55.7 x 21.3 x 21.75
150/138
*AM7A0C36H31SA
200-230/1/60
See O.D. Specifications
Plate Fin
3 - 14
5.50
3/8
EEV
3/4 NPT
See Outline Drawing
Centrifugal
11 X 10
1
Direct - Variable
See Fan Performance Table
1 - 1/2
Variable ECM
208-230/1/60
3.0
No
Throwaway
1 - 22 X 20 - 1 in.
R-410A
Brazed
7/8
3/8
H x W x D
57.25 x 25.25 x 23.5
56.9 x 23.5 x 21.75
157/146
PRODUCT SPECIFICATIONS
MODEL
RATED VOLTS/PH/HZ.
RATINGS 1
INDOOR COIL — Type
Rows — F.P.I.
Face Area (sq. ft.)
Tube Size (in.)
Refrigerant Control
Drain Conn. Size (in.) 2
DUCT CONNECTIONS
INDOOR FAN — Type
Diameter-Width (In.)
No. Used
Drive - No. Speeds
CFM vs. in. w.g.
No. Motors — H.P.
Motor Speed RPM
Volts/Ph/Hz
F.L. Amps
FILTER
Filter Furnished?
Type Recommended
No.-Size-Thickness
REFRIGERANT
Ref. Line Connections
Coupling or Conn. Size — in. Gas
Coupling or Conn. Size — in. Liq.
DIMENSIONS
Crated (In.)
Uncrated
WEIGHT
Shipping (Lbs.) / Net (Lbs.)
*AM7A0C42H31SA
200-230/1/60
See O.D. Specifications
Plate Fin
4 - 14
5.04
3/8
EEV
3/4 NPT
See Outline Drawing
Centrifugal
11 X 10
1
Direct - Variable
See Fan Performance Table
1 - 1/2
Variable ECM
208-230/1/60
3.0
No
Throwaway
1 - 22 X 20 - 1 in.
R-410A
Brazed
7/8
3/8
H x W x D
57.25 x 25.25 x 23.5
56.9 x 23.5 x 21.75
162/151
*AM7A0C60H51SA
200-230/1/60
See O.D. Specifications
Plate Fin
4 - 14
5.96
3/8
EEV
3/4 NPT
See Outline Drawing
Centrifugal
11 X 10
1
Direct - Variable
See Fan Performance Table
1 - 3/4
Variable ECM
208-230/1/60
5.5
No
Throwaway
1 - 22 X 20 - 1 in.
R-410A
Brazed
7/8
3/8
H x W x D
62.75 x 25.25 x 23.5
61.7 x 23.5 x 21.75
175/163
*AM7A0C48H41SA
200-230/1/60
See O.D. Specifications
Plate Fin
4 - 14
5.96
3/8
EEV
3/4 NPT
See Outline Drawing
Centrifugal
11 X 10
1
Direct - Variable
See Fan Performance Table
1 - 3/4
Variable ECM
208-230/1/60
4.2
No
Throwaway
1 - 22 X 20 - 1 in.
R-410A
Brazed
7/8
3/8
H x W x D
62.75 x 25.25 x 23.5
61.7 x 23.5 x 21.75
175/163
* May be "A" or "T"
1 These Air Handlers are AHRI certified with various Split System Air Conditioners and Heat Pumps (AHRI STANDARD 210/240).
2 3/4" Male Plastic Pipe (Ref.: ASTM 1785-76)
