32-5052-06 5
User’s Information
NOTE THE LOCATION OF THE MANUAL MAIN GAS SHUTOFF VALVE FOR YOUR FURNACE.
Have your installer or servicer show you the location if you have any questions.
UPFLOW FURNACE Manual Main Gas Shut-off Valve
May Be Located on the Left or Right Side
HORIZONTAL FURNACE Manual Main Gas Shut-off
Valve May Be Located on the Top or Bottom Side
HORIZONTAL FURNACE GAS PIPING MAY BE FROM EITHER SIDE
(Typical UPFLOW Furnace in horizontal configuration shown)
AUTOMATIC GAS VALVE
WITH MANUAL SHUTOFF
AUTOMATIC GAS VALVE
WITH MANUAL SHUTOFF
MAIN MANUAL
SHUTOFF VALVE
MAIN MANUAL
SHUTOFF VALVE
GROUND UNION
JOINT
GROUND UNION
JOINT
DRIP LEG
DRIP LEG
AIR FLOW
AIR FLOW
LEFT SIDE PIPING (STANDARD)
TOP VIEW OF RIGHT SIDE PIPING
RIGHT SIDE PIPING (OPTIONAL)
