VAV-SVX08R-EN
23
Figure 15. Low-height series DS02/PS02/DS03 w/hot water or electric heat
32.3
[821]
41.2
[1047]
2.0
[51]
41.2
[1047]
32.3
[821]
61.2
[1555]
Primary Airflow
Airflow Plenum
Inlet
Airflow
Discharge Outlet
Primary Airflow
Airflow Plenum
Inlet
Airflow Discharge
Outlet
Optional Electric
Heater
Water Coil
UUnniitt IInnssttaallllaattiioonn
