Table 10. Low–height series units — lb/kg
Unit Size
Single Wall
Dual Wall
LSxF
Attenuator
LSCF LSEF
LSWF
LSCF LSEF
LSWF
1–Row 2–Row 1–Row 2–Row
04DS02
89/41 107/49 95/43 97/44 112/51 130/59 118/54 120/55 14/6
04PS02
91/42 108/49 97/44 99/45 114/52 131/60 120/55 122/55 14/6
05DS02
89/41 107/49 95/43 97/44 112/51 130/59 118/54 120/55 14/6
05PS02
91/42 108/49 97/44 99/45 114/52 131/60 120/55 122/55 14/6
06DS02
88/40 106/48 94/43 96/44 111/50 129/59 117/53 119/54 14/6
06PS02
90/41 108/49 96/44 98/45 113/51 131/60 119/54 121/55 14/6
06DS03
94/43 112/51 100/45 104/47 117/53 135/61 123/56 127/58 14/6
08DS02
89/41 107/49 95/43 97/44 112/51 130/59 118/54 120/55 14/6
08PS02
91/42 108/49 97/44 99/45 114/52 131/60 120/55 122/55 14/6
08DS03
95/43 113/51 101/46 105/48 118/54 136/62 124/56 128/58 14/6
10DS03
97/44 115/52 103/47 107/49 120/55 138/63 126/57 130/59 14/6
14RTDS02
107/49 119/54 107/49 109/50 130/59 142/65 130/59 132/60 14/6
14RTPS02
109/50 121/55 109/50 111/50 132/60 144/65 132/60 134/61 14/6
14RTDS03
100/45 118/54 106/48 110/50 122/55 140/64 128/58 132/60 14/6
Table 11. Chilled water sensible coil terminal units — lb/kg
Unit Size
Single Wall
Dual Wall
LDCF LDEF
LDWF
LDCF LDEF
LDWF
1–Row 2–Row 1–Row 2–Row
DS02
125/57 143/65 131/59 135/61 148/67 166/75 154/70 158/72
UUnniitt IInnssttaallllaattiioonn
