Table 19. VSxF 06SQ ECM CFM (continued)
Airflow
(Min CFM: 700,
Max CFM: 2500)
Trane
Controller
PWM Signal
(a)
ECM Control
Board Signal
(b) (c)
CFM
L/s
% Setting
0-10V 2-10V
1870 882 65% 6.5 7.2
1960 925 70% 7.0 7.6
2050 967 75% 7.5 8.0
2140 1010 80% 8.0 8.4
2230 1052 85% 8.5 8.8
2320 1095 90% 9.0 9.2
2410 1137 95% 9.5 9.6
2500 1180 100% 10.0 10.0
(a)
% setting from Trane unit controller via pulse width modulating
signal or ECM control board with manual fan speed adjust setting.
(b)
ECM control board with 0-10 VDC fan modulation input and separate
fan on/off binary input required.
(c)
ECM control board with 2-10 VDC, has combined fan on/off and
modulation input where fan comes on when signal rises to 2 VDC and
goes off when signal falls to 1 VDC.
Table 20. LSxF DS03 ECM CFM
Airflow
(Min CFM: 100,
Max CFM: 1300)
Trane
Controller
PWM Signal
(a)
ECM Control Board
Signal
(b) (c)
CFM
L/s
% Setting
0-10V 2-10V
100 47 0% 0.0 2.0
160 76 5% 0.5 2.4
220 104 10% 1.0 2.8
280 132 15% 1.5 3.2
340 160 20% 2.0 3.6
400 189 25% 2.5 4.0
460 217 30% 3.0 4.4
520 245 35% 3.5 4.8
580 274 40% 4.0 5.2
640 302 45% 4.5 5.6
700 330 50% 5.0 6.0
760 359 55% 5.5 6.4
820 387 60% 6.0 6.8
880 415 65% 6.5 7.2
940 444 70% 7.0 7.6
1000 472 75% 7.5 8.0
1060 500 80% 8.0 8.4
1120 529 85% 8.5 8.8
1180 557 90% 9.0 9.2
Table 20. LSxF DS03 ECM CFM (continued)
Airflow
(Min CFM: 100,
Max CFM: 1300)
Trane
Controller
PWM Signal
(a)
ECM Control Board
Signal
(b) (c)
CFM
L/s
% Setting
0-10V 2-10V
1240 585 95% 9.5 9.6
1300 613 100% 10.0 10.0
(a)
% setting from Trane unit controller via pulse width modulating
signal or ECM control board with manual fan speed adjust setting.
(b)
ECM control board with 0-10 VDC fan modulation input and separate
fan on/off binary input required.
(c)
ECM control board with 2-10 VDC, has combined fan on/off and
modulation input where fan comes on when signal rises to 2 VDC and
goes off when signal falls to 1 VDC.
Table 21. LSxF, LpxF, LDxF DS02 ECM CFM
Airflow
(Min CFM: 400,
Max CFM: 1800)
Trane
Controller
PWM Signal
(a)
ECM Control Board
Signal
(b) (c)
CFM
L/s
% Setting
0-10V 2-10V
400 189 0% 0.0 2.0
470 222 5% 0.5 2.4
540 255 10% 1.0 2.8
610 288 15% 1.5 3.2
680 321 20% 2.0 3.6
750 354 25% 2.5 4.0
820 387 30% 3.0 4.4
890 420 35% 3.5 4.8
960 453 40% 4.0 5.2
1030 486 45% 4.5 5.6
1100 519 50% 5.0 6.0
1170 552 55% 5.5 6.4
1240 585 60% 6.0 6.8
1310 618 65% 6.5 7.2
1380 651 70% 7.0 7.6
1450 684 75% 7.5 8.0
1520 717 80% 8.0 8.4
1590 750 85% 8.5 8.8
1660 783 90% 9.0 9.2
1730 816 95% 9.5 9.6
1800 849 100% 10.0 10.0
(a)
% setting from Trane unit controller via pulse width modulating
signal or ECM control board with manual fan speed adjust setting.
(b)
ECM control board with 0-10 VDC fan modulation input and separate
fan on/off binary input required.
(c)
ECM control board with 2-10 VDC, has combined fan on/off and
modulation input where fan comes on when signal rises to 2 VDC and
goes off when signal falls to 1 VDC.
