GENERAL INFORMATION
64
Note
The use of leaded fuel is illegal in some
countries, states or territories.
Note
If 'knocking' or 'pinging' occurs at a
steady engine speed under normal
load, use a different brand of gasoline
or gasoline which has a higher octane
rating.
Oxygenated Gasoline
To help in meeting clean air standards,
some areas of the U.S. use oxygenated
gasoline to help reduce harmful
emissions. These gasolines are a
blend of conventional gasoline and
another compound such as alcohol.
This Triumph motorcycle will give its
best performance when using unleaded
gasoline. However, the following should
be used as a guide if you use any
oxygenated fuels.
Ethanol
Ethanol fuel is a mixture of 10% Ethanol
and 90% gasoline and is often described
under the names 'gasohol', 'Ethanol
enhanced', or 'contains Ethanol'. This
fuel may be used in your Triumph
motorcycle.
MTBE (Methyl Tertiary Butyl Ether)
The use of gasolines containing up to
15% MTBE (Methyl Tertiary Butyl Ether)
is permitted in this Triumph motorcycle.
Methanol
Fuels containing methanol should not be
used as damage to components in the
fuel system can be caused by contact
with methanol.
Note
Because of the generally higher
volatility of oxygenated fuels, starting,
engine response and fuel consumption
may be adversely affected by their
use. Should any of these difficulties be
experienced, run the motorcycle on
normal unleaded gasoline.
Refueling
Warning
To help reduce hazards associated
with refueling, always observe the
following fuel safety instructions:
- Gasoline (fuel) is highly flammable
and can be explosive under certain
conditions. When refueling, turn the
ignition switch to the OFF position.
- Do not smoke.
- Do not use a mobile telephone.
- Make sure the refueling area is well
ventilated and free from any source
of flame or sparks. This includes any
appliance with a pilot light.
- Never fill the tank until the fuel level
rises into the filler neck. Heat from
sunlight or other sources may cause
the fuel to expand and overflow
creating a fire hazard.
- After refueling always check that the
fuel filler cap is correctly closed.
- Because gasoline (fuel) is highly
flammable, any fuel leak or spillage,
or any failure to observe the safety
advice given above will lead to a fire
hazard, which could cause damage to
property, injury to persons or death.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Triumph Thruxton RS and is the answer not in the manual?

Triumph Thruxton RS Specifications

General IconGeneral
Displacement1200 cc
Max Torque112 Nm @ 4, 250 rpm
Transmission6-speed
Seat Height810 mm
Dry Weight197 kg
Bore x Stroke97.6 mm x 80 mm
Fuel SystemMultipoint sequential electronic fuel injection
Final DriveChain
Front Tyre120/70 ZR17
Rear Tyre160/60 ZR17
Wheelbase1415 mm
Engine TypeLiquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Max Power105 PS (77 kW) @ 7, 500 rpm
Front SuspensionShowa 43mm USD big piston forks, adjustable compression damping, rebound damping and preload
Rear SuspensionÖhlins twin shocks with adjustable preload
Front BrakesBrembo M50 4-piston radial monobloc calipers, twin 310mm floating discs, ABS
Rear BrakesSingle 220mm disc, Nissin 2-piston sliding caliper, ABS
Fuel Tank Capacity14.5 litres
FrameTubular steel with aluminium cradle
Front Wheel32-spoke, 17 x 3.5 in
Rear Wheel32-spoke, 17 x 5 in
